Allmand MAXI-LITE II V-Series 6-Light Tower-MLV6-C1.1

<UL><LI>Engine Brand:Caterpillar<LI>Engine Model:C1.1<LI>EPA Emission Level:Tier 4 Final<LI>Prime Output @ Rated Speed of 1800 RPM (HP):13.3<LI>Prime Power:8<LI>Engine Electrical System:12V; Glow plug cold starting<LI>Battery (CCA @ 0 deg F - Standard):550.0<LI>Fuel Capacity:100<LI>Operating Time (hrs) (using four 320 W LED light fixtures):228<LI>Light Type:N/A<LI>Wattage:N/A<LI>Lumens (per lamp):N/A<LI>Lumens (total):N/A<LI>Number of Luminaires- LED's:6<LI>LED Light Type:Two LED, 5000 deg K color temperature<LI>LED Wattage:320<LI>LED Lumens (per lamp):38,500<LI>LED Lumens (total):231,000<LI>Lighting Features:Sequenced Lighting System (SLS). System automatically turns on lights after engine start and delays engine shutdown to turn off lights first to prevent generator from shutting down while under load.<LI>Generator (Alternator):8kW, Marathon, (1)-30 AMP RV, (6) Conssin Led Lights, Gold<LI>Tower Maximum Height:332<LI>Tower Features:Structure - six section tubular steel design Actuation - hydraulic cylinder Guide pads - polyethylene self lubricating Manual winch to raise Balloon Light from installation position to operating position<LI>Power Cable:Power cable encased in Nycoil flexible tubing<LI>Fixture Positioning:Light bar with fixtures can be rotated 359 deg and fixtures can be adjusted with tower in lowered position.<LI>Towing Connection:"Adjustable height combination 2 in. (50.8 mm) ball coupler, 3 in. (76.2 mm) lunette ring for pintle hitch Adjustable height Standard - 2 in (50.8 mm) ball coupler<LI>Trailer:Frame - Formed, welded steel frame Axle - tubular axle with elliptical leaf springs Tires - ST205/75R 15 radial load range 'C' Doors - Stamped steel gull-wing style with lockable latch Standard features - Fluid Containment System (FCS) holding up to 110% of all on-board fluids - Remote engine oil and coolant drain easily accessible at rear of trailer - Forklift pockets - below-the-frame - Lift ring - Tie down rings - Removable tongue<LI>Trailer Lighting:Stop, turn, tail lights / side marker lights / illuminated license plate bracket Standard - 4-way flat connector<LI>Operating Wind Speed:65<LI>Stabilizers:Five-point design - tongue jack, two retractable side outriggers at front of trailer, two retractable side outriggers at rear of trailer</UL>
